140 products found.
SERIES 126.V0
coupling, protected by twisting the locking nut, Article: NB390
Image similar to the original Article: NB390, Nominal Width|7.8 mm, Connection|LW9, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: hose connection, connection size: LW9, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, hose connection, LW9, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: LW9 LW9 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 161.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1AC0
Image similar to the original Article: O1AC0, Nominal Width|8.5 mm, Connection|LW9, Flow Rate|1,966 l/min
Nominal width 8.5 mm, material: steel, surface: zinc-plated, single shut off, connection type: ferrule, connection size: LW9, seal: NBR (Perbunan) Two-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip AISI 301. Balls stainless steel AISI 420. Seals made from material NBR (Buna N). Plug: steel zink plated Nominal width 8.5 mm, steel, surface: zinc-plated, single shut off, ferrule, LW9, seal: NBR (Perbunan)
Nominal Width: 8.5 mm 8.5 Connection: LW9 LW9 Flow Rate: 1,966 l/min 1,966
more Details
SERIES 126.V0
coupling, protected by twisting the locking nut, Article: NB700
Image similar to the original Article: NB700, Nominal Width|7.8 mm, Connection| 1/4, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: male thread DIN2999 (BSPT), connection size: 1/4, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, male thread DIN2999 (BSPT), 1/4, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: 1/4 1/4 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 161.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1AG0
Image similar to the original Article: O1AG0, Nominal Width|8.5 mm, Connection| 1/4, Flow Rate|1,966 l/min
Nominal width 8.5 mm, material: steel, surface: zinc-plated, single shut off, connection type: female thread DIN228/1 (BSP), connection size: 1/4, seal: NBR (Perbunan) Two-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip AISI 301. Balls stainless steel AISI 420. Seals made from material NBR (Buna N). Plug: steel zink plated Nominal width 8.5 mm, steel, surface: zinc-plated, single shut off, female thread DIN228/1 (BSP), 1/4, seal: NBR (Perbunan)
Nominal Width: 8.5 mm 8.5 Connection: 1/4 1/4 Flow Rate: 1,966 l/min 1,966
more Details
SERIES 126.VS
coupling, protected by twisting the locking nut, hexagonal, Article: NB710
Image similar to the original Article: NB710, Nominal Width|7.8 mm, Connection| 1/4, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: male thread DIN2999 (BSPT), connection size: 1/4, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, male thread DIN2999 (BSPT), 1/4, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: 1/4 1/4 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 126.V0
coupling, protected by twisting the locking nut, Article: NB800
Image similar to the original Article: NB800, Nominal Width|7.8 mm, Connection| 1/4, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: female thread DIN228/1 (BSP), connection size: 1/4, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, female thread DIN228/1 (BSP), 1/4, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: 1/4 1/4 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 100.B0
coupling, Basic, Article: N8840
Image similar to the original Article: N8840, Nominal Width|7.2 mm, Connection| 3/8, Flow Rate|875 l/min
Nominal width 7.2 mm, material: brass, single shut off, connection type: male thread DIN228/1, connection size: 3/8, seal: NBR (Perbunan) One-hand coupling with 2-point bolt locking. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position and pushes the plug out of the coupling. Material coupling: connection, base body, valve and sleeve brass. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: brass. Nominal width 7.2 mm, brass, single shut off, male thread DIN228/1, 3/8, seal: NBR (Perbunan)
Nominal Width: 7.2 mm 7.2 Connection: 3/8 3/8 Flow Rate: 875 l/min 875
more Details
SERIES 161.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1AE0
Image similar to the original Article: O1AE0, Nominal Width|8.5 mm, Connection| 1/4, Flow Rate|1,966 l/min
Nominal width 8.5 mm, material: steel, surface: zinc-plated, single shut off, connection type: male thread DIN228/1, connection size: 1/4, seal: NBR (Perbunan) Two-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip AISI 301. Balls stainless steel AISI 420. Seals made from material NBR (Buna N). Plug: steel zink plated Nominal width 8.5 mm, steel, surface: zinc-plated, single shut off, male thread DIN228/1, 1/4, seal: NBR (Perbunan)
Nominal Width: 8.5 mm 8.5 Connection: 1/4 1/4 Flow Rate: 1,966 l/min 1,966
more Details
SERIES 126.V0
plug, protected by twisting the locking nut, Article: OMF62
Image similar to the original Article: OMF62, Nominal Width|7.8 mm, Connection|LW9, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: steel, surface: zinc-plated, connection type: hose connection, connection size: LW9 One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, steel, surface: zinc-plated, hose connection, LW9
Nominal Width: 7.8 mm 7.8 Connection: LW9 LW9 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 161.0S
plug, hexagonal, Article: OMA70
Image similar to the original Article: OMA70, Nominal Width|8.5 mm, Connection|LW9, Flow Rate|1,966 l/min
Nominal width 8.5 mm, material: steel, surface: zinc-plated, connection type: ferrule, connection size: LW9 Two-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip AISI 301. Balls stainless steel AISI 420. Seals made from material NBR (Buna N). Plug: steel zink plated Nominal width 8.5 mm, steel, surface: zinc-plated, ferrule, LW9
Nominal Width: 8.5 mm 8.5 Connection: LW9 LW9 Flow Rate: 1,966 l/min 1,966
more Details
SERIES 160.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1A40
Image similar to the original Article: O1A40, Nominal Width|5 mm, Connection|LW9, Flow Rate|910 l/min
Nominal width 5.0 mm, material: steel, surface: zinc-plated, connection type: ferrule, connection size: LW9, seal: FPM (Viton) Two-hand coupling with 2-point bolt locking. Single piece coupling body with connection - ideal for absorbing significant bending and torsion forces. Positive connection between coupling and plug. Counter nut prevents the connection from being opened unintentionally. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip stainless steel AISI 301. Bolts stainless steel AISI 316. Seals made from material FPM (Viton). Plug: steel zink plated Nominal width 5.0 mm, steel, surface: zinc-plated, ferrule, LW9, seal: FPM (Viton)
Nominal Width: 5 mm 5 Connection: LW9 LW9 Flow Rate: 910 l/min 910
more Details
SERIES 126.VS
coupling, protected by twisting the locking nut, hexagonal, Article: NB720
Image similar to the original Article: NB720, Nominal Width|7.8 mm, Connection|LW9, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: hose connection, connection size: LW9, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, hose connection, LW9, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: LW9 LW9 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 090.V0
coupling, protected by twisting the locking nut, Article: N0QA0
Image similar to the original Article: N0QA0, Nominal Width|5 mm, Connection| 1/4, Flow Rate|600 l/min
Nominal width 5.0 mm, material: brass, surface: nickel plated, single shut off, connection type: male thread DIN228/1, connection size: 1/4, seal: FPM (Viton) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part, sleeve and coupler body brass nickel plated. Valve brass nickel plated. Locking nut anodised aluminium. Seal FPM ( Viton). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: brass nickel plated Nominal width 5.0 mm, brass, surface: nickel plated, single shut off, male thread DIN228/1, 1/4, seal: FPM (Viton)
Nominal Width: 5 mm 5 Connection: 1/4 1/4 Flow Rate: 600 l/min 600
more Details
SERIES 126.VS
coupling, protected by twisting the locking nut, hexagonal, Article: NB760
Image similar to the original Article: NB760, Nominal Width|7.8 mm, Connection|LW12, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: hose connection, connection size: LW12, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, hose connection, LW12, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: LW12 LW12 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 160.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1A20
Image similar to the original Article: O1A20, Nominal Width|5 mm, Connection|LW9, Flow Rate|910 l/min
Nominal width 5.0 mm, material: steel, surface: zinc-plated, single shut off, connection type: ferrule, connection size: LW9, seal: FPM (Viton) Two-hand coupling with 2-point bolt locking. Single piece coupling body with connection - ideal for absorbing significant bending and torsion forces. Positive connection between coupling and plug. Counter nut prevents the connection from being opened unintentionally. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip stainless steel AISI 301. Bolts stainless steel AISI 316. Seals made from material FPM (Viton). Plug: steel zink plated Nominal width 5.0 mm, steel, surface: zinc-plated, single shut off, ferrule, LW9, seal: FPM (Viton)
Nominal Width: 5 mm 5 Connection: LW9 LW9 Flow Rate: 910 l/min 910
more Details
SERIES 160.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1A10
Image similar to the original Article: O1A10, Nominal Width|5 mm, Connection|LW13, Flow Rate|910 l/min
Nominal width 5.0 mm, material: steel, surface: zinc-plated, connection type: ferrule, connection size: LW13, seal: FPM (Viton) Two-hand coupling with 2-point bolt locking. Single piece coupling body with connection - ideal for absorbing significant bending and torsion forces. Positive connection between coupling and plug. Counter nut prevents the connection from being opened unintentionally. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip stainless steel AISI 301. Bolts stainless steel AISI 316. Seals made from material FPM (Viton). Plug: steel zink plated Nominal width 5.0 mm, steel, surface: zinc-plated, ferrule, LW13, seal: FPM (Viton)
Nominal Width: 5 mm 5 Connection: LW13 LW13 Flow Rate: 910 l/min 910
more Details
SERIES 126.VS
coupling, protected by twisting the locking nut, hexagonal, Article: NB730
Image similar to the original Article: NB730, Nominal Width|7.8 mm, Connection| 1/4, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: female thread DIN228/1 (BSP), connection size: 1/4, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, female thread DIN228/1 (BSP), 1/4, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: 1/4 1/4 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 160.VS
coupling, protected by twisting the locking nut, hexagonal, Article: O1A30
Image similar to the original Article: O1A30, Nominal Width|5 mm, Connection| 1/4, Flow Rate|910 l/min
Nominal width 5.0 mm, material: steel, surface: zinc-plated, single shut off, connection type: male thread DIN228/1, connection size: 1/4, seal: FPM (Viton) Two-hand coupling with 2-point bolt locking. Single piece coupling body with connection - ideal for absorbing significant bending and torsion forces. Positive connection between coupling and plug. Counter nut prevents the connection from being opened unintentionally. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip stainless steel AISI 301. Bolts stainless steel AISI 316. Seals made from material FPM (Viton). Plug: steel zink plated Nominal width 5.0 mm, steel, surface: zinc-plated, single shut off, male thread DIN228/1, 1/4, seal: FPM (Viton)
Nominal Width: 5 mm 5 Connection: 1/4 1/4 Flow Rate: 910 l/min 910
more Details
SERIES 160.0S
plug, hexagonal, Article: OMAL0
Image similar to the original Article: OMAL0, Nominal Width|5 mm, Connection|LW9, Flow Rate|910 l/min
Nominal width 5.0 mm, material: steel, surface: zinc-plated, connection type: ferrule, connection size: LW9 Two-hand coupling with 2-point bolt locking. Single piece coupling body with connection - ideal for absorbing significant bending and torsion forces. Positive connection between coupling and plug. Counter nut prevents the connection from being opened unintentionally. Coupling body, sleeve and locking nut are made from steel zink plated. Valve brass. Spring and circlip stainless steel AISI 301. Bolts stainless steel AISI 316. Seals made from material FPM (Viton). Plug: steel zink plated Nominal width 5.0 mm, steel, surface: zinc-plated, ferrule, LW9
Nominal Width: 5 mm 5 Connection: LW9 LW9 Flow Rate: 910 l/min 910
more Details
SERIES 126.V0
coupling, protected by twisting the locking nut, Article: NB394
Image similar to the original Article: NB394, Nominal Width|7.8 mm, Connection|LW8, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: hose connection, connection size: LW8, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, hose connection, LW8, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: LW8 LW8 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 126.V0
coupling, protected by twisting the locking nut, Article: NB880
Image similar to the original Article: NB880, Nominal Width|7.8 mm, Connection| 3/8, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: female thread DIN228/1 (BSP), connection size: 3/8, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, female thread DIN228/1 (BSP), 3/8, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: 3/8 3/8 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 126.0S
plug, hexagonal, Article: OMMV0
Image similar to the original Article: OMMV0, Nominal Width|7.8 mm, Connection|LW12, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: steel, surface: zinc-plated, connection type: hose connection, connection size: LW12 One-hand coupling with automatic 5-point locking. Locking elements are balls that are locked by a spring-loaded unlocking sleeve. The uncoupling process is initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position closes the couling and pushes the plug out of the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. The positive connection between the coupling and the plug allows to transmitted torsional forces. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, steel, surface: zinc-plated, hose connection, LW12
Nominal Width: 7.8 mm 7.8 Connection: LW12 LW12 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 126.V0
coupling, protected by twisting the locking nut, Article: NB384
Image similar to the original Article: NB384, Nominal Width|7.8 mm, Connection|LW13, Flow Rate|2,030 l/min
Nominal width 7.8 mm, material: brass, surface: nickel plated, single shut off, connection type: hose connection, connection size: LW13, seal: NBR (Perbunan) One-hand coupling with automatic 5-point locking. Locking elements are balls which are locked by a spring-loaded unlocking sleeve. Disconnect by pushing the release sleeve back into the direction of the connection. The valve moves back to its original position and closes the coupling. All couplings in this series have an additional lock nut to secure the coupling against accidental uncoupling. Material coupling: back part and body are made of brass nickel plated. Valve brass. Sleeve steel hardend nickel plated. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Balls stainless steel AISI 420. Material plug: steel hardend zink plated. Nominal width 7.8 mm, brass, surface: nickel plated, single shut off, hose connection, LW13, seal: NBR (Perbunan)
Nominal Width: 7.8 mm 7.8 Connection: LW13 LW13 Flow Rate: 2,030 l/min 2,030
more Details
SERIES 100.Z0
coupling, protected by twisting the sleeve, Article: N1ZW4
Image similar to the original Article: N1ZW4, Nominal Width|7.2 mm, Connection| 1/4, Flow Rate|1,350 l/min
Nominal width 7.2 mm, material: brass, surface: nickel plated, single shut off, connection type: male thread DIN228/1, connection size: 1/4, seal: NBR (Perbunan) One-hand coupling with 2-point bolt locking. To avoid unintentional uncoupling, the release sleeve can only be opened by turning it manually in one position. The uncoupling process is then initiated by pushing back the unlocking sleeve into the direction of the connection. The valve moves back to its original position and pushes the plug out of the coupling. Material Coupling: back part, sleeve, coupler body are made of brass nickel plated. Valve brass. Seal NBR (Buna N). Spring and circlip stainless steel AISI 301. Bolts stainless steel AISI 316. Material plug: brass nickel plated Nominal width 7.2 mm, brass, surface: nickel plated, single shut off, male thread DIN228/1, 1/4, seal: NBR (Perbunan)
Nominal Width: 7.2 mm 7.2 Connection: 1/4 1/4 Flow Rate: 1,350 l/min 1,350
more Details
